2MP HDCVI IR Bullet Camera Dahua DH HAC-HFW1200S
KSh 2,450.00
The parameters and datasheets below can only be applied to 1200-S5 series
> Max 30fps@1080P
> HD and SD output switchable
> 3.6mm fixed lens (2.8 mm, 6 mm optional)
> Max. IR length 30m, Smart IR
> IP67, DC12V
Dahua HD Camera HAC-HFW-1200RP Specifications
| Model | DH-HAC-HFW1200SP | ||
| Camera | |||
| Image Sensor | 1/2.7″ 2Megapixel CMOS | ||
| Effective Pixels | 1920(H)×1080(V) | ||
| Electronic Shutter | 1/25~1/100000s | ||
| Video Frame Rate | 25/50fps@720P; 25fps@1080P | ||
| Synchronization | Internal | ||
| Min. Illumination | 0.02Lux/F2.0, 0Lux IR on | ||
| Video Output | 1-channel BNC high definition video output/ CVBS standard definition video output (Can switch) | ||
| Camera Features | |||
| Max. IR LEDs Length | 30m, Smart IR | ||
| Backlight Compensation | DWDR | ||
| Day/Night | Auto(ICR) / Color / B/W | ||
| Noise Reduction | 2D | ||
| OSD Menu | Support | ||
| Lens | |||
| Focal length | 3.6mm (6mm optional) | ||
| Angle of View | H: 89.9º(59.4º) | ||
| Mount Type | M12 | ||
| General | |||
| Power Supply | DC12V±25% | ||
| Power Consumption | Max 4W | ||
| Working Environment | -40°C~+60°C / Less than 95%RH (no condensation) | ||
| Transmission Distance | Over 500m via 75-3 coaxial cable | ||
| Ingress Protection | IP67 | ||
| Dimensions(W×D×H) | Φ70mm×165mm | ||
| Weight | 0.35kg | ||
| Material | Metal (body) + Plastic (sunshield) | ||
